Heinkel He 50
Type: Reconnaissance & dive bomber
Origin: Ernest Heinkel AG
Models: A to B
First Flight: 1931
Service Delivery: 1933
Final Delivery: N/A
Production: N/A
Engine: Typical
Model: Bramo SAM 22B (322B)
Type: 9-Cylinder Radial
Number: One      Horsepower: 650 hp
Dimensions:
Wing span: 37 ft. 8¾ in. (11.50m)
Length: 31 ft 6 in. (9.60m)
Height: 14 ft. 5¼ in. (4.40m)
Wing Surface Area: N/A
   Weights: He 50A
Empty: 3,528 lbs. (1600 kg)
Maximum: 5,777 lbs. (2620 kg)
Performance:
Maximum Speed: 146 mph (235 kph)
Initial climb: N/A
Service Ceiling: N/A
Range at 110 mph (177 kph): 373 Miles (600 km)
Armament:
One MG 17 machine gun firing forward. One 7.92mm MG 15 Machine gun in observers cockpit*.
*Optional if observer carried.

Payload:
1,102 lb. (500 kg) bombs.
Or 551 lb. (250 kg) bombs if observer carried.
