Type: Carrier based Fighter Origin: Grumman Crew: One Model: XF5F-1 First Flight: April 1, 1940 Production: 1 Prototype Engine: Model: Wright XR-1820-40/42 Type: 9-Cylinder radial aircooled engine Number: Two Horsepower: 1,200 hp Dimensions: Wing span: 42 ft. 0 in. Length: 28 ft. 8.5 in. Height: 11 ft. 4 in. Wing Surface Area: 303.5 sq. ft. (?m²) Weights: Empty: 8,107 lb. Loaded: 10,138 lb. |
Performance: Maximum Speed: 383 mph at sea level 380 mph at 16,500 ft. Cruising Speed: N/A Climb Rate: 4,000 ft./minute Service Ceiling: 33,000 ft. Absolute Ceiling: 34,200 ft. Maximum Range: N/A Armament: Four .50 in. machine guns. Ammunition: 400 rounds per gun. Bomb Load: Two 165 lb bombs.  |
|
BACK TO EXPERIMENTAL MENU |
BACK TO MAIN MENU |
| Sources: Green, William - War Planes Of The Second World War - Fighters - Vol. 4, 1964, Doubleday And Company, Inc., New York |
