Specifications
Manufacturer: Curtiss-Wright
First flight: May 3 1943
Crew: 1-2
Number built: 14
– 5 production C-76
– 9 revised YC-76A
Powerplant:
Model: Pratt & Whitney R-1830-92 Twin Wasp
Type: 14-Cylinder, two row, radial piston engine
Horsepower: 1,200 hp each
Number: Two
Dimensions:
Length: 68.33 ft (20.83 m)
Wingspan: 108.17 ft (32.97 m)
Height: 27.25 ft (8.31 m)
Wing area: 1560.05 ft² (144.93 m²)
Weights:
Empty weight: 18262 lb (8301 kg)
Max. takeoff weight: 28000 lb (12701 kg)
Performance:
Maximum speed: 192 mph (309 kph)
Cruise speed: 160 mph (260 kph)
Range: 750 mi (1207 km)
Service ceiling: 22,600 ft (6,888 m)
