BRISTOL BEAUFORT
Specifications


[Source: Unknown]

Type: Four-Seat Torpedo Bomber
Origin: Bristol
Models: Mark I to VIII
First Flight: October 15, 1938
Service Delivery: October 1939
First Flight (Australia, Mark V):
    August 1941
Final Delivery (Australia): August 1944
Number Produced:
    2,080 (700 Australian built)

Engine:
Mark I, II (from number 166 on), III, IV
  Model: Bristol Taurus VI
  Type: 14 Cylinder Sleeve-valve radial
  Number: Two    Horsepower: 1,130 hp

Mark II (First 165), V through VIII
  Model: Bristol Taurus VI
  Type: 14 Cylinder Sleeve-valve radial
  Number: Two    Horsepower: 1,130 hp

Dimensions:
Wing span: 57 ft. 10 in. (17.63m)
Length: 44 ft. 2 in. (13.46m)
Height: 14 ft. 3 in. (4.34m)
Wing Surface Area: N/A

Weights:
Empty: 13,107 lbs. (5945 kg)
Max. Take-Off: 21,230 lbs. (9629 kg)
  Performance:
Maximum Speed:
    Clean: 260 mph (418 km/h)
    With Torpedo: 225 mph (362 km/h)
Initial climb: N/A
Service Ceiling: 16,500 ft. (5030m)
Range: 1,600 Miles (2575 km)

Armament:
Typical:
Two .303 in. Vickers K in dorsal turret.
One .303 in. Vickers K in left wing.

Alternate:
Four .303 in. Brownings in wing.
Two .303 in. Brownings manually aimed from beam windows.

Mk. II and final 140 Australian Mk. VIII:
Four .303 in. Brownings in wing.
Two .303 in. Brownings manually aimed from beam windows.
Two .303 in. Brownings in dorsal turret.

Payload:
One 18 in. torpedo mounted semi-externally to left of centerline or bomb load of 2,000 lb. (907 kg.)
