Type: Reconnaissance fighter Crew: Two Origin: Bayerische Flegzeugwerke Powerplant: Model: Daimler-Benz DB 601N Type: Liquid-cooled, inverted V12 Number: Two Horsepower: 1,200 hp Fluids: Fuel Capacity: 279 Imperial Gallons in wing cells Type: N/A Oil Capacity: 7.7 Imperial Gallons per engine Dimensions: Wing span: 53 ft. 4¾ in. (16.25m) Length: 39 ft. 8½ in. (12.1m) Height: 11 ft. 6 in. (3.5m) Wing Surface Area: 413 Sq. ft. |
Weights: Empty: 4,500kg (9,920 lbs.) Loaded: 7,000kg (15,430 lbs.) Performance: Maximum Speed: 349 mph (562 kph) at 22,965 ft (7,000m) Range: 528 mls (850 km) at 304 mph (490kph) at 16,400 ft. (5,000m) Initial climb: to 5,500m (18,045 ft.) in 8 minutes Service Ceiling: 32,800 ft. (10,000m) Armament: Rear Gun in flexible mounting in rear cockpit One 7.9mm MG 15 Machine Gun with 750 rounds. Racks for two 250kg bombs. Optics/Photographic Equipment: Serial camera Rb 50/30 |
Gunston, Bill - The Encyclodepia of the Worlds Combat aircraft, 1976, Chartwell Books, Inc., New York
Brown, Eric, Captain - Wings of the Luftwaffe
, 1979, Airlife Publishing Ltd., ShrewsburyGunston, Bill & Wood, Tony - Hitler's Luftwaffe
, 1977, Salamander
Books Ltd., LondonDonald, David - The Complete Encyclopedia Of World Aircraft, 1997, Brown Packaging Books Ltd., London
