Type: Four or five seat medium bomber
Origin: Ernst Heinkel AG
First Flight:
    He-111H-1: Early 1939
Service Delivery: N/A
Final Delivery:
    He-111H-23: October 1944
Production: N/A

---

Powerplant:
He-111H-0 & H-1:
   Model: Junkers Jumo 211A
   Type: Liquid cooled inverted V-12
   Number: Two      Horsepower: 1,100 hp

He-111H-3:
   Model: Junkers Jumo 211D-2
   Type: Liquid cooled inverted V-12
   Number: Two      Horsepower: 1,200 hp

He-111H-20/R4:
   Model: Junkers Jumo 213E-1
   Type: Liquid cooled inverted V-12 with 2-stage
       supercharger & GM-1 power boost.
   Number: Two      Horsepower: 1,750 hp

---

Fluids:
Fuel:
   Capacity: 748 Imp. Gal. (3,400 liters) in wing cells
   Type: N/A

Oil Capacity N/A

---

Dimensions: He-111H-3
Wing span: 22.6m (74 ft 1.75 in.)
Length: 16.4m (53 ft. 9.5 in.)
Height: 4m (13 ft. 1.5 in.)
Wing Surface Area: N/A

Weights:
Empty: 7,720kg (17,000 lbs.)
Loaded: 14,000kg (30,865 lbs.)

Performance:
Maximum Speed:
    Empty: 258 mph (415 kph)
    Loaded: 205 mph
Range:
    Loaded: 745 miles (1200 kilometers)
Initial climb:
    Empty: to 4,500m (14,765 ft.) in 30-35 minutes
    Empty: to 4,500m (14,765 ft.) in 50 minutes
Service Ceiling: 25,590 ft. (7,800m)

---

Armament:
One 7.92mm MG 15 machine gun on manual mount in nose cap
One 7.92mm MG 15 machine gun on manual mount in dorsal position
One 7.92mm MG 15 machine gun on manual mount in ventral gondola
Two 7.92mm MG 15 machine gun on manual mounts in waist windows
One 7.92mm MG 15 or MG 17 machine gun on fixed mount firing forward
One 20mm MG FF cannon on fixed mount in front part of ventral gondola's
Optional
One 7.92mm MG 15 machine gun on manual mount in side of nose (for co-pilot?)
One 7.92mm MG 17 machine gun on fixed mount in extreme tail

Bombload:
Up to 4,410lb (2000kg) of bombs mounted in vertical cells, stored nose up.

Avionics:
FuG 10 radio equipment

Sources:
Gunston, Bill & Wood, Tony - Hitler's Luftwaffe, 1977, Salamander Books Ltd., London
WikiPedia - Heinkel He 111
Brown, Eric, Captain - Wings Of The Luftwaffe, 1979, Airlife Publishing Ltd., Shrewsbury
The Complete Encyclodepia of World Aircraft, 1997, Barnes & Nobles Books, ISBN: 0 7607 0592 5
