Type: Single-seat fighter
Origin: Bayerische Flegzeugwerke

---

Powerplant:

• Model: Daimler-Benz 605
• Type: Liquid Cooled Inverted V12
• Horsepower: 1,550hp

---

Dimensions:

• Wing span: 32 ft. 6½ in.
• Length: 29 ft. 4 in.
• Height: 8 ft. 6 in.
• Wing Surface Area: N/A

---

Weights:

• Empty: N/A
• Maximum, Loaded: 7,438 lb.

---

Performance:

• Maximum Speed: 452 mph at 19,685 ft.
• Maximum Climb: 4,823 feet per minute
• Range: 365 Miles
• Service Ceiling: 41,000 ft.

---

Armament:

• One 30mm MG 103 or 30mm MG 108 mounted between cylinder heads and firing through the propeller hub.
• Two 15mm MG 17 mounted above engine.

Sources:
Gunston, Bill - The Encyclodepia of the Worlds Combat aircraft, 1976, Chartwell Books, Inc., New York
Brown, Eric, Captain - Wings of the Luftwaffe, 1979, Airlife Publishing Ltd., Shrewsbury
Gunston, Bill & Wood, Tony - Hitler's Luftwaffe, 1977, Salamander Books Ltd., London
Donald, David - The Complete Encyclopedia Of World Aircraft, 1997, Brown Packaging Books Ltd., London
Scutts, Jerry - Messerschmitt BF109: The Operational Record, 1996, Airlife Publishing Ltd, UK
Wikipedia - BF 109
