Specifications
|
Type: Attack Origin: Beech Crew: Two Model: Beech Model 28 First Flight: May 7, 1944 Final Delivery: N/A Aircraft Produced: 2 Engine: Model: Wright R-3350-43 Cyclone Type: Radial piston engine Number: Two Horsepower: 2,300 hp Dimensions: Wing span: 67 ft. 4 in. (20.52m) Length: 51 ft. 9 in. (15.77m) Height: 15 ft 6 in (4.72 m) Wing Surface Area: 626 ft² (58.15 m²) |
Weights: Empty: 22,480 lb (10,197 kg) Loaded: 35,264 lb. (15,995 kg) Performance: Maximum Speed: 370 mph (595 kph) at 17,000 ft (5,180 m) Rate of Climb: 2,600 ft/min (13.2 m/s) Service Ceiling: 29,000 ft (8,840 m) Range: 1,625 miles (2,615 km) Armament: 1 × T15E1 75 mm cannon with 20 rounds. 6 × .50 M2 Browning machine guns – 2 forward-facing in nose – 2 in ventral turret – 2 in dorsal turret |
The Complete Encyclodepia of World Aircraft, 1997, Barnes & Nobles Books, ISBN: 0 7607 0592 5
